TRIOMF GRAXER
TRIOMF GRAXER
Couldn't load pickup availability
TRIOMF GRAXER is crafted from full carbon Toray 700 and 800 materials, ensuring a lightweight yet robust structure designed for gravel riding. With a weight of just 1230g in size M, it features a 1-1/2″ head tube for improved steering precision, along with a T47 bottom bracket for optimal power transfer.
Equipped with a UDH rear hanger and internal cable routing for a clean aesthetic and enhanced performance, the frameset accommodates modern disc brakes with a flat mount design. This setup provides reliable stopping power, making it a practical choice for versatile gravel adventures while maintaining a refined ride quality.
| Brand | TRIOMF |
|---|---|
| Model | GRAXER |
| Material | Full Carbon Toray 700&800 Super Light |
| Available Size | XS/S/M/L/XL |
| Head Tube | 1-1/2” |
| Seat Post | ∅27.2mm |
| Bottom Brackst | T47 |
| Rear hanger | UDH |
| Cable Routing | Internal Cable Routing(For RB/FD/RD) |
| Cable Plug Mechanical and DI2 | 2 in 1 |
| Grade Available Weight | Size XS:1200g, S: 1258gm, M:1234g, L:1240g, XL: 1304g |
| Tire Max | 700X45C |
| O.L.D Axle | 142mm |
| Disc brake | Flat mount, Front 160 / Rear 160 |
| Steerer Slze | 1-1/2” |
| Steerer Length | 300mm |
| Offset | 50mm |
| O.L.D TA | 100mm |
| Test | EN test / UCI test |
Internal Cable Routing
The frame’s internal cable routing design effectively reduces external cable friction and wear, enhancing the bike’s aesthetic while reducing air resistance. This design not only offers a cleaner appearance but also improves cable protection and durability, making the bike suitable for all weather conditions during rides.
